Product Details:
|
| Product Name: | Homogenizer For Beverage | Application: | Juicer Or Jam Production Line |
|---|---|---|---|
| Function: | Fruit Vegetable Processing | Brand: | YGT |
| Place Of Origin: | Shanghai,China | Voltage: | 380V 50HZ |
| Certification: | CE | Warranty: | 1Year |
| Materical: | SUS304 | Capacity: | 500L/h |
| Highlight: | 500L Per Hour High Shear Homogenizer,SUS304 Material High Shear Homogenizer |
||
SUS304 Material High Shear 500L Per Hour Homogenizer For Dairy Beverage
The precise coordination of the rotor and the stator, the claw structure of the working head (manufactured by the rotor and the stator forging), the bidirectional suction, and the high shearing efficiency.
Intermittent high shear dispersing emulsification homogenizer is a high-frequency, strong circular tangential velocity, angular velocity and other comprehensive kinetic energy through the high-speed and stable rotation of the rotor.
Efficiency; under the action of the stator, a strong, reciprocating hydraulic shear, friction, centrifugal extrusion, liquid collision and other comprehensive effects are formed in the reasonably narrow gap between the stator and the rotor, and the material circulates in the container. get product.
Homogenizer is a kind of equipment used to homogenize and emulsify liquid materials (liquid-liquid phase or liquid-solid phase) with viscosity lower than 0.2Pa.s and temperature ≤85℃. Mainly used in food or chemical industry , such as:
homogenization and emulsification in the production process of dairy products, beverages, cosmetics, pharmaceuticals and other products. Application of homogenizer in food processing: Homogenizer in food processing refers to refining the material under the triple action of extrusion, strong impact and pressure loss expansion, so that the material can be More uniform mixing, such as the use of a homogenizer in dairy processing to break down the fat in the milk more finely, so that the entire product system is more stable. Milk will look whiter. Homogenization is mainly carried out by a homogenizer. It is an important processing equipment in the food, dairy and beverage industries.
OVERVIEW
TECHNICAL DATA SHEET
| Driving assembly | House is made of grey cast iron HT200, and crank shaft, connecting rod, and gears are made of ductile cast iron. |
| Plunger | the 4th generation stainless alloy(PH-type) |
| Check valve | the 4th generation stainless alloy (GrMoFr), abrade-resisting and impact-resisting |
| Pump block | stainless steel |
| Plunger sealing | X4310 and PP spacer with heat-proof reaching 100℃ |
| Homogenizing valve | the 3rd special stainless alloy |
| Size | 1.3*1.0*1.1m |
| Weight | 1500kg |
| Voltage | 380V 50Hz |
Equipment Description:
The machine is made up of the foundation, motor, gearbox, high pressure pump and
homogenizing component etc..
Main applications:
(1) cell disruption, process new products, or harvesting the intracellular products;
(2) subdividing the particles or droplets present in fluids into very smallest sizes ( submicron ) and creating a stable dispersions and emulsions;
(3) homogenizing many other products;
Widely applied in fields of food, genetic engineering, chemical industry, pharmacy etc.
Working Principle:
when product is flowing through the adjustable valve ,the particles or droplets present in mixed
fluids with high pressure will be subdivided into the very smallest sizes (diameter Φ=0.1~0.2 um,
average Φ ≤1um ) because of pressure decrease, expansion, explosion, cutting and high-speed
impacting etc., then the emulsions or dispersions could be produced. This process refer to the
following Fig.
Through homogenizing the stability, easy-absorb, long-life, taste and color etc. of product could be
realized.
