Product Details:
Payment & Shipping Terms:
|
| Voltage: | 380V/50HZ | Warranty: | 1 Year |
|---|---|---|---|
| Material: | SS304/SS316L | Condition: | New |
| Name: | Beverage Bottle Filling Line | Function: | Filling |
| Capacity: | 4000-6000bph | ||
| High Light: | food processing machinery,coconut oil processing machine |
||
Application:
This machine is designed for small capacity wine factory and big company make many
different kinds of wine as sample, because it is suitable for kinds of glass bottle filling,
like square bottle, round bottle,flat bottles and so on.
1.The filling line use direct connection technology between air conveyor and in-feeding star-wheel to substitute in-feeding screw and conveyor to ease the process of bottle-size-changing.
2. Neck-hanging technology is applied in bottle transportation of the automatic water filling machine. Instead of traditional star-wheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only arch board and star-wheel such little nylon parts need to be changed.
3. Specially-designed rinsing grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution in this automatic water filling machine.
4. Rapid gravity filling valve with high flow makes filling faster with accurate liquid level and without any liquid loss.
5. Splint of star-wheel using twist descending way to simplify the process of bottle-size-changing.
Matched equpment system
0. pretreatment(blending-sterilizer-holding tank)
1, conveyor
2, cap elevator
3, vaccuum pump
4, feeding pump
5. labeling machine
6. Package machine
7. Ink coder
Parameter for our filling machine :
| Model | YGT12/12/4 | YGT18/18/6 | YGT24/24/6 | YGT32/32/8 |
| Production capacity(500ml) | 1000-1200B/H | 2000-3000B/H | 4000-5000B/H | 7000-8000B/H |
| Total power | 1.5Kw | 1.5Kw | 3.75Kw | 5.6Kw |
| Weight | 2000Kg | 2400Kg | 3000Kg | 3500Kg |
| Overall dimension | 1700x1100x2300mm | 1830x1320x2300mm | 1950x1580x2500mm | 2100x1850x2500mm |
