Product Details:
|
Voltage: | 220V,380V | Weight: | Different |
---|---|---|---|
Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
Condition: | New | Type: | Juicer |
Material: | Stainless Steel,SUS304 | Function: | Extractor,Multifunctional |
Feature: | Easy Operation | Usage: | Industrial Usage,Commercial Usage,Juicer Extractor |
Highlight: | Commercial Fruit Juicer Production Line,Multifunction Fruit Juicer Processing Machine |
Introduction:
1.The machine must be installed horizontally and fixed with foot screws.
2.Operation: when the equipment is started, the pressure head should be adjusted to make the ring clearance reach the maximum, then the clearance gradually decreases to reach the process, and then the brake should be used to fix the position of the handwheel bearing seat.
3, feeding must be uniform, strictly prohibit hard foreign matter into the hopper, so as not to damage the screen.
4.Maintenance: the filter must be washed with water and brush after each shift.If the juice with more fiber is filtered, it is necessary to increase the net washing time according to the production condition, and clean all the machines with hot water after the press is finished.
Application:
1, suitable for ginger, garlic, wheat seedlings, tomatoes, carrots, potatoes, sweet potatoes, golden needle silk, leek, celery, cabbage, green vegetables, pumpkin, cucumber, onion and other vegetables juice.
2, suitable for apple, pear, grape, roxburgh rose, cantaloupe, strawberry, raspberry, kiwi, pineapple, lemon, watermelon coconut, blueberry, pure thorn fruit fruit juice.
3, suitable for fruit and vegetable garbage, kitchen garbage juice dehydration.
Advantages:
1.304 stainless steel body, durable, full oxidation resistance.
2. Screw juicing machine is suitable for pressing all kinds of fruits and vegetables.
3. Motor protection, energy saving.
4. Simple operation and easy cleaning.
5. Support customization.
6. There are also crushing juicers and other equipment.
Technical Parameter:
Model | QD-PLZ0.5 | QD-PLZ1 | QD-PLZ1.5 | QD-PLZ2.5 |
capacity(t/h) | 0.1-0.5t | 1t | 1.5t | 2.5t |
dimension(mm) | 1000*330*1220 | 1150*380*1220 | 500*480*1400 | 2090*700*1560 |
Weight(kg) | 115 | 155 | 280 | 630 |
Power(kw) | 1.5+2.2 | 1.1+2.2 | 1.5+4 | 5.5+15 |
Screw diameter(mm) | 88 | 125 | 175 | 250 |
Screen pore size(mm) | 0.6MM | 0.6MM | 0.6MM | 0.6MM |
